| Product module | IMHSS03 |
| Brands | ABB |
| Payment | Paypa/TT |
| Condition | 100% New |
| Weight | 0.56KG |
| Production year | 2024 |
| Country of origin | SWEDEN |
ABB IMHSS03 Description
The IMHSS03 Hydraulic Servo module is a valve position control module.
It provides an interface through which a Harmony controller can drive
a servo valve or I/H converter to provide manual or automatic control of a hydraulic actuator.
The controller utilizes function code 55 or 150 (hydraulic servo) to configure and
access the module input/output channels. Typical uses for the module are positioning of
steam turbine throttle and control valves, gas turbine fuel valves, inlet guide vanes,
and nozzle angle. By regulating the current to the servo valve, the IMHSS03 module
can initiate a change in actuator position.
If you want to know more, please contact us!
Looking forward to your contact.
feature
| 1.Analog Input/Output Functions |
Provides additional analog input and output channels for measuring and controlling process variables. |
| 2.Enhanced Communication Capabilities: |
May support various communication protocols, allowing better integration of the drive with other devices and systems. |
| 3.Modular Design |
The plug-in design makes installation and maintenance more convenient. |
About ABB IMHSS03 Specifications
The ABB IMHSS03 is an advanced slot module designed for ABB variable frequency drives (VFDs)
to enhance their functionality and meet the complex demands of industrial automation systems.
This module provides essential analog input/output functions and communication capabilities,
making it highly effective in various applications.The IMHSS03 module features multiple high-precision
analog input and output channels. These analog inputs are used for real-time monitoring
Users can quickly replace or upgrade the module without affecting system operation,
thereby reducing downtime and maintenance costs. of process variables
such as temperature, pressure, or flow, ensuring data accuracy and effective control.
Recommended model
| ABB | SPFEC12 | Analog Input Module |
| ABB | SPBRC410 | Controller with Modbus TCP Interface |
| ABB | 086348-001 | Control Module |
| ABB | TU831V1 3BSE013235R1 | Extended Module Termination Unit |
| ABB | AGPS-21C | Power Supply Module |
| ABB | SDCS-PIN-51 3BSE004940R0001 | Measurement Card |
| ABB | SPS03-5V 2VAA008280R001 | Power Supply Unit |
| ABB | PPD113 3BHE023784R2630 B01-26-111000 | AC 800PEC Module |
| ABB | 3BHE022287R0001 UCD240A01 UC D240 A01 | Converter Module |
| ABB | SPCD 3D53-AB | Circuit Board |
Please contact us and look forward to our cooperation!
ABB 07KT92 GJR5250500R0202 is 07 KT 92 Central Unit - 90 Series 24 VDC Power Supply CPU - 14 K FLASH EPROM twelve 24 VDC inputs Eight 24 VDC/ 0.5A transistor outputs 4 analogue inputs 12 bits resolution 2 analogue output 12 bits resolution 2 programmable RS 232 port RS 485 system The Dimensions is 24 cm x 13.7 cm x 8.5 cm, and the weight is 1 lbs 10.1 oz (0.64 kg ).
ABB DSPC172H 5731001-MP Master CPU Module DSPC172H ABB Master CPU Module Model Type: 57310001-MP/2 DSPC 172H ABB Master CPU Module, article number 57310001-MP/2. Firmware prom sub-modules. Dimensions: 5.1 cm x 25.4 cm x 25.4 cm Weight: 2 lbs 8.0 oz (1.1kg ) Series: ABB Master series module
ABB DSQC201 YB560103-AB Robot Module DSQC 201 Robot Module Model Type: YB560103-AB Dimensions: 15.2 cm x 2.5 cm x 22.9 cm Weight: 0 lbs 6.0 oz (0.2kg ) Series: ABB Robots robotics series module
ABB DSQC541 PCB Backplane Controller Card DSQC541 DSQC 541 Backplane Card module Model Type: DSQC541 DSQC 541 Input Voltage: 24V DC Operating Temperature: 0°C to 45°C Storage Temperature: -25°C to 70°C Dimensions: 19.2 cm x 12.5 cm x 22.9 cm Weight: 0 lbs 6.0 oz (0.220 kg ) Series: ABB Robots robotics series module
ABB DSQC608 3HAC12934-1 Robotics Power Supply Module DSQC608 3HAC12934-1 DSQC 608 Model Type: 3HAC12934-1 Input Voltage: 24V DC Operating Temperature: 0°C to 45°C Dimensions: 7.1x13.5x18.5cm Weight: 1.380 kg Series: ABB Robots robotics IRC5 Single series module
ABB DSQC643 3HAC024488-001/01 Controller Panel Board DSQC 643 DSQC643 3HAC024488-001/01 Model Type: 3HAC024488-001/01 Input Voltage: 24V DC Operating Temperature: 0°C to 45°C ROBOTICS FOR IRC5 CABINET WITH FLAT DOORS Dimensions: 28x20.3x2.7cm Weight: 0.400 kg Series: ABB Robots robotics controller IRC5 Single series module
ABB IMDSO14 Digital Output Slave Module Parts Type: Digital Output Slave Model Type: Bailey Infi 90 IMDSO14 Digital Output Slave, 16-Channel Open Collector, Power Requirements +5 VDC, 370 mA Dimensions: 17.8 cm x 5.1 cm x 33.0 cm Weight: 0.200 kg Series: ABB Bailey Infi 90, ABB Bailey Infi 90 and Net 90
ABB MB510 3BSE002540R1 Program Card Interface Module Parts Type: MB510 Program Card Interface Model Type: 3BSE002540R1 Country of Origin: Sweden Dimensions: 2.2x17x10.2cm Weight: 0.1400 kg Series: Advant OCS with Master, Advant Controller 450RMC
