ABB NDBU-85C Field Kit

ABB NDBU-85C Field Kit

⇒ Model Number NDBU-85C
⇒ Country of Origin:  Sweden
⇒ Description: Field Kit
⇒ Shipping Worldwide by DHL /Fedex /TNT / UPS
⇒ Weight

0.72KG

⇒ Dimensions 26.3x9.5x5.5cm


Mobile :86-18020776792        Email : sales@amikon.cn

What’s app:86-18020776792  Skpye:miyazheng520

ABB NDBU-85C Product Parameters

The ABB NDBU-85C is a type of network distribution control unit used in electrical distribution systems.
1. Electrical Ratings
Nominal Voltage: 230V AC or 400V AC
Frequency:  50/60 Hz.
2.Control and Monitoring
Display: LCD or LED
3.Operating Conditions
Temperature Range:
-5°C and 40°C (23°F to 104°F)
4.Enclosure and Mounting
Enclosure Type:
IP20, IP65

Overview of ABB NDBU-85C

Purpose and Function Key Features Technical Specifications
Network Distribution Control: The NDBU-85C is used to manage and control distribution networks, ensuring reliable and efficient operation. Real-Time Monitoring: Monitors electrical parameters such as voltage, current, and power quality, providing essential data for system management. Nominal Voltage:230V AC or 400V AC
Monitoring and Protection: It provides real-time monitoring, control, and protection for electrical distribution systems. Protection Functions: Includes protection mechanisms for overloads, short circuits, and earth faults to ensure system safety and reliability. Frequency:50 Hz or 60 Hz
Control Capabilities: Allows for local and remote control of distribution network devices. Temperature Range:-5°C to 40°C (23°F to 104°F)

Common Issues and Solutions for ABB NDBU-85C

1. Device Not Powering On

Possible Causes:Incorrect or disconnected power supply.

Solutions:Check Power Connections: Ensure that the power connections are secure and properly connected

2. Faulty Display or Interface Issues

Possible Causes:Display or interface module failure.

Solutions:Check Connections: Ensure that all connections to the display or interface module are secure.

3. Inaccurate Monitoring Data

Possible Causes:Sensor calibration issues.

Solutions:Calibrate Sensors: Perform calibration checks on the sensors to ensure accurate readings.

4. Communication Failures

Possible Causes:Faulty communication cables or connections.

Solutions:Inspect Cables and Connections: Check all communication cables and connections for damage or loose connections.
