| Specifications and Features | |
| • Model | ⇒ SAM02 R1H |
| • Part Number |
⇒ ANR27900579 |
| Functionality |
|
|
• Protection |
⇒ Provides comprehensive protection functions, including overcurrent, earth fault, and differential protection. |
| • Control | ⇒ Capable of managing and controlling various aspects of the power system, such as switching operations and system status monitoring. |
| Inputs and Outputs | |
| • Inputs | ⇒ Designed to accept inputs from current transformers (CTs) and voltage transformers (VTs) to monitor electrical parameters. |
| • Outputs | ⇒ Includes relay outputs for fault signaling and control functions. These outputs can be used to trigger alarms or disconnect faulty equipment. |
Choosing us is the best decision！
Welcome to contact Miya！
86-18020776792 86-18020776792 sales@amikon.cn
Main Functions
The ABB SAM02 R1H is a state-of-the-art protection relay designed to deliver comprehensive protection, monitoring, and control
functions for medium and high voltage electrical systems. This advanced device is engineered to enhance the safety and reliability of power
networks by offering a range of sophisticated protection features. It provides robust overcurrent protection to safeguard against excessive
currents that can damage electrical equipment, while its earth fault protection effectively identifies and mitigates ground faults to prevent potential
hazards. Additionally, the relay includes differential protection, which compares the current entering and leaving a protected zone, such as a
transformer or generator, to detect and isolate internal faults that could compromise system integrity.The SAM02 R1H is also equipped with
various control functions that facilitate the automation of power system management. It supports switching control for operating circuit breakers
and other devices, thereby streamlining the control of electrical systems and reducing the need for manual intervention. The relay's automation
capabilities include automatic reclosure and fault isolation, which improve system reliability by quickly restoring normal operation after a fault
and isolating faulty sections to minimize disruption.In terms of monitoring and diagnostics, the SAM02 R1H offers real-time visibility into the
electrical system's performance. It continuously tracks critical parameters such as current, voltage, and frequency, providing up-to-date information
on system health. The device also features detailed event logging, which records fault occurrences and other significant events. This data is
invaluable for analyzing system behavior, troubleshooting issues, and planning maintenance activities.The relay is designed with communication
in mind, supporting industry-standard protocols such as IEC 61850 and Modbus. This allows for seamless integration with SCADA systems and
other control networks, enabling centralized monitoring and management of the electrical network. The user-friendly interface of the SAM02 R1H
includes a display that simplifies the process of configuration and real-time monitoring. This intuitive interface allows operators to
easily set protection parameters, view system status, and access historical data.
