Product module | PR6423/13R-030 CON021 |
Brands | EMERSON |
Payment | Paypal/TT |
Condition | 100%New |
Weight | 0.54KG |
Production year | 2024 |
Contry origin | USA |
Decription
Part number :PR6423/13R-030 CON021 |
Linear Measurement Range :2 mm (80 mils) |
Initial Air Gap :0.5 mm (20 mils) |
Incremental Scale Factor (ISF) :ISO: 8 V/mm (203.2 mV/mil) ± 5% @ temperature range 0 to 45°C (+32 to +113°F) |
Deviation from best fit straight line (DSL) :± 0.025 mm (± 1 mil) @ temperature range 0 to 45°C (+32 to +113°F) |
Minimum Shaft Diameter :25 mm (0.79”) |
Target Material (Ferromagnetic Steel): 42CrMo4 (AISI/SAE 4140) Standard Other (On Request) |
Operating Temperature Range Sensor incl. 1m Cable: -35 to +200°C (-31 to 392°F) |
Dimensions:31x26x8cm |
PR6423/13R-030 CON021 is a powerful and widely used eddy current sensor. It adopts non-contact measurement method to accurately
measure the thickness, conductivity, and distance between the probe and the metal surface of the metal material by detecting the
response of the target metal to high-frequency alternating magnetic field. This sensor has a wide range of applications in the field of industrial
automation, especially playing an important role in industries such as automotive manufacturing, aerospace, and metal processing.
working principle
When high-frequency alternating current passes through the sensor coil, eddy currents will be generated on the surface of the measured
metal. The size and phase of these eddies are closely related to the conductivity, permeability, and distance between the probe and the metal surface
of the metal. Sensors precisely measure the magnetic field changes generated by these eddy currents, convert these physical
quantities into electrical signals, and undergo complex signal processing to obtain accurate measurement results
Email: sales@amikon.cn
Freequently Asked Questions About PR6423/13R-030 CON021
What is PR6423/13R-030 CON021 Eddy Current Sensor? |
The PR6423/13R-030 CON021 is a non-contact sensor used to measure the thickness of metallic materials, conductivity, and the distance between the probe and the metal surface. It achieves measurement by detecting the response of the target metal to a high-frequency alternating magnetic field. |
What is the measurement principle of this sensor? |
When a high-frequency alternating current passes through the sensor coil, eddy currents are generated in the surface of the measured metal. The magnitude and phase of the eddy currents are closely related to the conductivity, permeability, and distance of the metal from the sensor probe. The sensor measures the changes in the magnetic field generated by the eddy currents to obtain these parameters. |
Where is this sensor applicable? |
This sensor is widely used in automotive manufacturing, aerospace, metal processing, and power industries, for measuring the thickness of metal sheets, coating thickness, conductor thickness, etc. |
How to install this sensor? |
Installation steps typically include:
|
