GENERAL ELECTRIC 269PLUS-D/O-216-100P-HI Digital Relay

269PLUS-D/O-216-100P-HI is a motor management relay that is manufactured by GE Multilin. This relay is 100 Ohm and has a

platinum RTD. The shipping box is 11.40 inches x 7.50 inches x 16.00 inches (W x H x D). The shipping weight is 7.75 lb.

The ambient temperature for storage and operation must fall between -25°C-60°C. The inputs on this relay include the

meter communication port, the spare input, the differential relay input, the speed switch input, the programming access jumper

or keyswitch, the external reset pushbutton, the emergency restart keyswitch, the 6 stator RTDs, the 4 additional RTDs,

the ground fault CTs, the phase CTs, the supply power terminals, and the universal AC/DC supply.

The typical motor protections include protecting the motors and equipment from operator abuse, protecting personnel

from shock hazards, protecting gears, pumps, fans, sawmills, cutters, and compressors from a mechanical jam, protecting

pumps from loss of suction or fans from loss of air flow, protecting the motor and the load bearings from the excessive heat

buildup due to mechanical wear, protecting motors that are operated in varying ambient temperatures,

protecting high inertia, long acceleration drive systems using a custom overload curve.
