GENERAL ELECTRIC 369-HI-R-M-0-0 Motor Management Relay

Motor Health Report: The relay can use learned information and history of system trips to identify when and where maintenance may be required.

Pre-Trip Alarms: The 369 can notify users prior to a trip when it is caused by ground faults, mechanical jams, RTD overtemperature, and more.

Oscillography: Three waveform records are triggered on trip and capture sixteen data cycles. Phase and ground currents and contact input status are both captured during this process.

Metering: The 369 can monitor quantities like voltage, watts, frequency, and energy, generating protective functions based on the value datas generated.

The 369-HI-R-M-0-0 Motor Management Relay is a sophisticated and versatile device designed for comprehensive motor protection, control, and monitoring in industrial applications. This relay is engineered to safeguard motors by providing real-time monitoring of critical parameters such as current, voltage, temperature, and power factor. It offers advanced protection features, including overload, underload, phase loss, and unbalanced voltage protection, ensuring the motor operates within safe limits.

Equipped with a high-precision microprocessor, the 369-HI-R-M-0-0 relay allows for precise detection of abnormal conditions, triggering alarms or shutdowns to prevent damage to the motor and associated equipment. The relay's modular design allows for easy integration into existing control systems, and it supports communication protocols such as Modbus, allowing for seamless data exchange and remote monitoring.

The 369-HI-R-M-0-0 relay also features an intuitive user interface with configurable settings, making it easy to tailor the relay's operation to specific application requirements. Its robust construction ensures reliable performance even in harsh industrial environments, making it an ideal solution for motor management in sectors like manufacturing, oil and gas, and power generation.
