| Product module | 745-W2-P5-G5-HI-A-R-E |
| Brands | GENERAL ELECTRIC |
| Payment | Paypal/TT |
| Condition | 100% New |
| Weight | 7.52KG |
| Production year | 2024 |
| country of origin | USA |
GE 745-W2-P5-G5-HI-A-R-E Protective Relay
Specification
| 745-W2-P5-G5-HI-A-R-E Protective Relay |
|
| 745 | 745 Transformer Protection System |
| W2 | Two windings per phase |
| P5 | Winding 1 = 5 A, Winding 2 = 5 A, Winding 3 = 5 A |
| G5 | Winding 1/2 = 5 A, Winding 2/3 = 5 A |
| HI | 90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz |
| A | Analog inputs/outputs |
| R | Restricted ground fault |
| E | Enhanced display, larger LCD |
| Dimension | 21.5x23x25cm |
Details
The 745-W2-P5-G5-HI-A-R-E is a GE 745 Transformer Management Relay. AX Control has a number of parts in this series available for purchase, typically
ready to ship from our warehouse upon order. 745 Protections system components are designed to deliver two or three windings and can be used
to manage and protect power transformers from small to large. This series is now in legacy status and is no longer available through the OEM.
The 745-W2-P5-G5-HI-A-R-E is offered as a base unit that has two windings per phase. This particular unit has 5A per winding, ½, and ⅔ winding. Control power for this
unit is rated at 90-300 VDC and 70-265 VAC @ 48-62 Hz. The unit has restricted ground fault. Inputs and Outputs are analog. The front panel display is enhanced with a larger LCD.
The 745-W2-P5-G5-HI-A-R-E meets applicable IEEE, ANSI, and NEMA standards. Please check with your local
codes and ordinances to ensure compliance. The unit is built using a standard SR-series arrangement, using a draw-out
relay and a companion case. The 745-W2-P5-G5-HI-A-R-E can be mounted on its own or it can be used along with other SR-series units. Wiring diagrams
can be found in original documentation like manuals and user guides. While these diagrams offer information about standard layouts, your situation may vary.
The 745-W2-P5-G5-HI-A-R-E front panel has a 40-character LCD display over three lines of LED indicators. The front panel also
offers an interface port to connect the unit to a computer along with control keys and a keypad for local control.
Email : sales@amikon.cn
Skype :miyazheng520
Phone/WhatsApp : 86-18020776792
Frequently Asked Questions
| What kind of display does the 745-W2-P5-G5-HI-A-R-E use? |
| The 745-W2-P5-G5-HI-A-R-E uses a basic, 40-character liquid crystal display. |
| What communications features does the 745-W2-P5-G5-HI-A-R-E have? |
| The 745-W2-P5-G5-HI-A-R-E has a front RS232 and rear RS485 port for communications. |
| What is the function of the 745-W2-P5-G5-HI-A-R-E Protective Relay? |
| The 745-W2-P5-G5-HI-A-R-E Protective Relay is designed to protect electrical systems and equipment from faults such as overloads, short circuits, and other abnormal conditions. |
| What are the key features of the 745-W2-P5-G5-HI-A-R-E Protective Relay? |
| The 745-W2-P5-G5-HI-A-R-E Protective Relay offers several key features, including programmable settings for various protective functions, high accuracy in fault detection, and robust performance in harsh environments. It includes customizable parameters for different protection schemes and has built-in diagnostics for easy troubleshooting and maintenance. The relay is designed to enhance the safety and reliability of electrical systems by providing reliable protection against a range of electrical faults. |
