GENERAL ELECTRIC 8421-CC-PS Controller power cable

Part Number：8421-CC-PS

Input wiring

Input wiring shall not be too long. However, if the environmental interference is small and the voltage drop is small, the input wiring can be appropriately longer.

Input/output lines cannot use the same cable, and input/output lines shall be separated.

Connect to the input terminal in the form of normally open contact as far as  possible to make the ladder diagram prepared consistent with the relay schematic  diagram for easy reading.

Output connection

Output terminal wiring is divided into independent output and common output. In different groups, different types and voltage levels of output voltage can be used. However, the output in the same group can only use the power supply of the same type and voltage level.

Since the output components of PLC are packaged on the printed circuit board and connected to the terminal board, if the load connecting the output components  is short circuited, the printed circuit board will be burned.

Dimensions：19x19x3cm

The 8421-CC-PS cable is designed for specific types of controllers to ensure a stable power connection. Please refer to the product documentation to confirm compatibility with your controller model.

The 8421-CC-PS cable generally includes protective features such as interference resistance and durability to meet industrial environment requirements. Specific protection levels can be found in the product specifications.

The 8421-CC-PS cable is specifically designed for certain brands and models of controllers and may not be compatible with controllers from other brands. Please verify compatibility to ensure correct usage.
