Product module | IC693MDL752 |
Brands | GENERAL ELECTRIC |
Payment | Paypal/TT |
Condition | 100% New |
Weight | 0.24KG |
Production year | 2024 |
country of origin | USA |
GE IC693MDL752 Positive/Negative Logic Input Module
Specification
Part No.: IC693MDL646 |
Manufacturer: General Electric |
Country of Manufacture: United States of America (USA) |
Rated Voltage: 24 volts DC |
Number of Inputs: 16 |
Input Current: 7.0 mA |
Input Voltage Range: 0 to -30 volts DC |
DC Power: Yes |
Product Type: Positive/Negative Logic Input Module |
Series: Mark I and II |
Dimensions :3.5x13x13.5cm |
Functional Description
The GE IC693MDL752 Positive/Negative Logic Input Module is a versatile component designed for use
with the GE Fanuc Series 90-30 PLC system. This module provides flexible input options by supporting
both positive and negative logic configurations, making it suitable for a wide range of industrial applications.
It is capable of handling discrete input signals, which can be configured to match the logic requirements
of various control systems. The IC693MDL752 features high reliability and durability, ensuring consistent performance
in demanding environments. Its ease of integration with the Series 90-30 PLC allows for straightforward
installation and maintenance, enhancing the overall efficiency and functionality of industrial automation systems.
Input Characteristics and Device Compatibility
The IC693MDL752 is engineered to accommodate a wide range of user-supplied input devices.
These devices include limit switches, push buttons, and proximity switches. The dual logic capabilities positive and
negative enhance its adaptability in different control systems, allowing for greater flexibility in designing and
configuring PLC systems. Power for the operation of these field devices is typically provided by the user,
either through a direct power supply or via an isolated +24VDC supply from the power supply unit.
LED Indicators for Status Monitoring
At the top of the module, there are LED indicators that serve as visual aids to display the ON/OFF status of each
input point. The LED block is divided into two horizontal rows, with each row containing eight green LEDs.
The top row is labeled A1 to A8, corresponding to input points 1 through 8, while the bottom row is labeled B1 to B8,
corresponding to input points 9 through 16. These LEDs are essential for quick status monitoring and troubleshooting in the field.
Wiring Diagram and Circuit Identification
The IC693MDL752 is designed with user convenience in mind, featuring an insert that fits between the inside and outside surfaces
of the hinged door. The wiring diagram is located on the inside of this insert, providing a clear reference for installation and maintenance.
On the outside surface of the insert, the circuit identification information is clearly displayed, facilitating easy access when needed.
The outside left edge of the insert is color-coded blue, indicating that the module is classified as a low-voltage device.
This color-coding aids in the quick identification of the module type during setup and maintenance.
Email : sales@amikon.cn
Skype :miyazheng520
Phone/WhatsApp : 86-18020776792
Freequently Asked Questions
What is IC693MDL646? |
It is a Positive/Negative Logic Input Module developed by GE under the Mark I and II series. |
How many input points does the module have? |
The module provides 16 input points, organized into a single group that shares a common power input terminal. |
What types of devices can be connected to the module? |
It is compatible with various user-supplied input devices, including limit switches, push buttons, and proximity switches. |
How are the status of the input points monitored? |
The module features LED indicators located at the top, divided into two horizontal rows of eight green LEDs each. The LEDs are labeled A1 to A8 for input points 1 through 8 and B1 to B8 for input points 9 through 16, showing the ON/OFF status of each input point. |
