Product model | T8461C |
Product Discription | TMR 24/48 Vdc Digital Output |
Brand | ICS TRIPLEX |
Weight | 950g(2.1 Ib) |
Condition | 100% New |
Production year | 2024 |
country of origin | USA |
Product detailed parameters
ICS TRIPLEX T8461C Product detailed parameters |
|
Field Supply | 60 Vdc maximum via T8461C |
Power Dissipation | 0.5 w per power group |
Operating Temperature | 0°Cto+ 60°C(+32 F to+140 °F) |
Storage Temperature | -25 °C to +70°C(-13°F to+158 °F) |
Relative Humidity - Operating and Storage | 10 % - 95 %。non-condensing |
Dimensions Height | 110 mm (4.33 in) |
Dimensions Width | 360 mm (14.17 in) |
Dimensions Depth | 68 mm (2.67 in) |
Weight | 950g(2.1 Ib) |
The Trusted® Triple Modular Redundant (TMR) 24V DC / 48V DC Digital Output Module interfaces to 40 field devices.
Triplicated diagnostic tests are performed throughout the Module including measurements for current,
and voltage on each portion of the voted output channel. Tests are also performed for stuck on and stuck off failures.
Fault tolerance is achieved through a TMR architecture within the Module for each of the 40 output channels.
ICS TRIPLEX T8461C Features:
• 40 TMR output channels per Module. |
• Comprehensive, automatic diagnostics and self-test. |
• Automatic line monitoring per channel to detect open circuit and short circuit field wiring and load faults. |
• 2500V impulse withstand opto/galvanic isolation barrier. |
• Automatic overcurrent protection (per channel), no external fuses required. |
• Onboard Sequence of Events (SOE) reporting with 1 ms resolution. |
• Module can be hot-replaced online using dedicated Companion (adjacent) Slot or SmartSlot (one spare slot for many Modules) configurations. |
• Front Panel output status light-emitting diodes (LEDs) for each channel indicate output status and field wiring faults. |
• Front Panel Module status LEDs indicate Module health and operational mode (Active, Standby, Educated). |
• Outputs are powered in isolated groups of eight. Each such group is a Power Group (PG). |
If you want to learn more details,please contact me without hesitate.
Email: sales@amikon.cn
Engineering drawing of ICS TRIPLEX T8461C
ICS Triplex is renowned for its high-integrity critical control solutions, especially in demanding industries such as oil
and gas, chemicals, and power generation. One of their standout products is the T8461C Trusted TMR 24/48Vdc
Digital Output Module. The ICS T8461C module is a key component in ensuring reliable and safe operations.
With its robust design and exceptional performance, the T8461C plays a crucial role in ICS Triplex's commitment
to excellence in industrial control systems. The ICS Triplex Digital Output Module offers high reliability
and exceptional performance, making it an ideal choice for critical industrial control systems.
The ICS T8461C is a 16-channel universal input module designed for the Woodward MicroNet control system.
The ICS T8461C module stands out with its robust design and advanced digital output capabilities, ensuring
high reliability and superior performance, making it indispensable for a wide range of rigorous industrial applications.
The T8461C not only delivers outstanding performance but also adapts to various harsh industrial environments,
ensuring high reliability under diverse complex operating conditions. Through the T8461C module,
ICS Triplex demonstrates its ongoing commitment to providing top-notch engineering services,
products, and solutions, particularly in industries requiring high-integrity control.
