AB 1794-IF4I Analog Input Module

AB 1794-IF4I Basic Features

• Four Analog Input Channels	Supports both voltage (0-10V, ±10V) and current (4-20 mA) inputs.	2.Chart
• High Resolution	16-bit resolution for precise analog-to-digital conversion.
• Accuracy	±0.1% of full scale, ensuring reliable measurements
• Signal Conditioning	Built-in filtering and amplification for accurate data.
• Electrical Isolation	Each channel is isolated from others and from the backplane to reduce interference.

Choose us was a best decision!

Welcome to contact Miya！

            86-18020776792                               86-18020776792                               sales@amikon.cn

Function and Purpose

AB 1794-IF4I

Graphs and figures

The Allen-Bradley 1794-IF4I analog input module is a crucial component of the POINT I/O™ system,

designed to provide precise and versatile analog signal measurement capabilities for industrial automation applications.

It features four analog input channels that can handle both voltage and current signals. This flexibility allows it to

interface with a variety of sensors and devices, accommodating measurements such as temperature, pressure,

and flow.The module supports voltage inputs with a range of 0 to 10V or ±10V and current inputs ranging from

4 to 20 mA. This adaptability ensures compatibility with different types of analog outputs. With a 16-bit resolution,

the 1794-IF4I delivers high precision in converting analog signals to digital data, providing detailed and accurate

measurements. The module's input accuracy of ±0.1% of full scale further enhances the reliability of the data.

Built-in signal conditioning features, including filtering and amplification, prepare the analog signals for conversion

by reducing noise and ensuring signal integrity. This conditioning process ensures that the data captured is clean

and reliable, which is essential for effective monitoring and control.The module enables real-time data acquisition,

allowing the POINT I/O™ system to continuously monitor and respond to changing conditions based on live data.

Each channel on the 1794-IF4I can be independently configured for different signal types and ranges.
