| Product module | 330101-30-63-15-02-CN |
| Brands | BENTLY NEVADA |
| Payment | Paypa/TT |
| Condition | 100% New |
| Weight | 0.12KG |
| Production year | 2024 |
| country of origin | USA |
330101-30-63-15-02-CN Proximity Probes Bently Nevada
overview
The Bently Nevada 330101-30-63-15-02-CN Proximity Probe is a high-performance device in the 3300 series proximity probe system,
designed to provide precise and reliable monitoring of rotational and reciprocating machinery. This proximity probe system is widely
used in industrial environments to measure and monitor the displacement and vibration of critical machinery components,
ensuring the normal operation and maintenance of equipment.
|
Contact us Email : sales@amikon.cn |
Specifications
| 330101-30-63-15-02-CN Proximity Probes |
|
| Supply Sensitivity | Less than 2 mV change in output voltage per volt change in input voltage |
| Output Resistance | 50 Ω |
| Power |
-17.5 Vdc to -26 Vdc without barriers at 12 mA maximum consumption
|
| Extended Temperature | 0 °C to +45 °C (+32 °F to +113 °F) |
| Frequency Response | 0 to 10 kHz |
| Standard cable | 75Ω triaxial |
| Dimensions | 22x20x2cm |
Graphs and Figures
 |
|
Product detailed description
The 330101-30-63-15-02-CN Proximity Probe comes with a 30-meter probe cable and a 63-meter extension cable, with a total length of 15 meters
(customizable based on user needs), ensuring the integrity and stability of signal transmission. The flexible cable length options make
it suitable for different installation environments and mechanical configurations. The probe is made of high-quality materials and can
operate stably in high temperatures, high pressure, and heavily contaminated environments. Its robust construction ensures reliable
performance under harsh industrial conditions, extending the equipment's service life.
The 330101-30-63-15-02-CN Proximity Probe is certified by relevant Chinese authorities, complying with local regulations and standards,
ensuring its applicability and compliance in the Chinese market. This certification guarantees product quality and performance reliability,
making it an ideal choice for Chinese users. The probe is designed with ease of installation in mind, featuring a standard M10x1 thread
size and an 8mm probe diameter, making it suitable for various mechanical equipment. The probe's ClickLoc connector ensures secure
and reliable connections, preventing loosening or disconnection in high-vibration environments.
Recommended model
| Bently Nevada | 330104-13-20-10-02-00 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330104-12-20-10-01-00 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330104-10-20-10-02-05 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330104-10-20-05-02-00 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330104-10-18-10-01-00 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330104-08-16-10-02-00 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330104-08-14-10-02-05 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330104-06-14-50-02-00 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330104-06-14-10-02-00 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330104-06-12-10-02-00 | 3300 XL 8mm Proximity Probe |
If you want to know more, please feel free to contact us via email: sales@amikon.cn
The 3500/22M 138607-01 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
3500/22M is a Transient Data Interface Module manufactured and designed by Bently Nevada as part of the 3500 Series used for monitoring seismic activity. The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
The 3500/33 16-Channel Relay Module is a full-height module that provides 16 relay outputs. You can place any number of 16-channel relay modules in any of the slots to the right of the Transient Data Interface (TDI) Module. Each output of the 3500/33 16-Channel Relay Module can be independently programmed to perform voting logic.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The 3500/60 133811-01 modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/72M Recip Rod Position Monitor meets API 618 requirements for reciprocating compressors. It measures: l Rod position l Rod drop l Hyper-compressor The four-channel 3500/72M Recip Rod Position Monitor accepts input from proximity transducers, conditions the signal to provide dynamic and static position measurements, and compares the conditioned signals with userprogrammable alarms. Each channel, depending on how you configure it, typically conditions its input signal to generate various parameters called measured values.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
