| Product module | 3500/94M 184826-01 |
| Brands | BENTLY NEVADA |
| Payment | Paypa/TT |
| Condition | 100% New |
| Weight | 0.78KG |
| Production year | 2024 |
| country of origin | USA |
| Inputs | |
| Power consumption | 4.6 watts max |
| High-speed network | Monitor status, data and values |
| RS232 port (I/0) | Touch controller data |
| Outputs | |
| OK LED | Indicates proper operation of the module |
| TX/RX LED | Indicates communications between other system modules |
| VGA port (I/O) | Analog red, green, blue and sync signals to the display |
| Front Port |
24 Vdc Power out, VGA signal out, Touch commands in. |
Compliance and Certifications
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
The Bently Nevada 3500/94M Main Module (Model 184826-01) is a critical component within the
Bently Nevada 3500 Series Machinery Protection System, designed to deliver advanced monitoring and protection for
essential rotating machinery.The 3500/94M Main Module is engineered to handle multiple input signals from various types of sensors, including
vibration sensors, proximity probes, and temperature sensors. This capability allows it to
monitor a range of machinery conditions in real-time, enabling the early detection
of issues such as imbalance, misalignment, or wear before they escalate into more serious problems.
| Dimensions (height x width x depth) | 241.3 mm x 24.4 mm x 241.8 mm (9.5 in x 0.96 in x 9.52 in) |
| Screen Size | 10 diagonal |
| Mounting Styles | Face Mount 19” Rack Mount Panel Mount Independent Mount |
| Power | 24 Vdc power supply included. (Permissible voltage range 10 Vdc to 28 Vdc) Inrush Current: 3.5 A @ 24 V (< 500 µs) Operating Current: < 500 mA |
| Agencies | CE, UL, CUL |
If you want to know more, please contact us!
Looking forward to your contact.
Email:sales@amikon.cn
About Bently Nevada 3500/94M 184826-01
The 3500/94M Main Module is engineered to handle multiple input signals from various types of sensors,
including vibration sensors, proximity probes, and temperature sensors. This capability
allows it to monitor a range of machinery conditions in real-time, enabling the early detection
of issues such as imbalance, misalignment, or wear before they escalate into more serious problems.
The module is known for its precision and reliability, offering high-resolution data
acquisition and processing to capture even minor changes in machinery condition.
This detailed monitoring helps in maintaining the machinery's health and preventing potential failures.
Equipped with advanced alarm and shutdown functions, the 3500/94M protects machinery
from damage by triggering alarms or automatic shutdowns based on predefined thresholds.
This proactive approach helps avert catastrophic failures and reduces downtime. Additionally,
the module features extensive data logging and analysis capabilities, recording historical
data and trends crucial for diagnosing issues, performing root cause analysis, and refining
maintenance strategies. The recorded data can be accessed and analyzed through
the Bently Nevada System 1 software, offering enhanced insights and reporting capabilities.
The module's modular and scalable design allows for flexible integration into the 3500 Series system,
making it adaptable to various machinery and application needs. This flexibility ensures
that the monitoring system can evolve alongside changing requirements.
Recommended model
| Bently Nevada | 990-10-XX-01-00 MOD:165353-01 | Vibration Transmitter |
| Bently Nevada | 990-10-XX-01-00 283278-01 | Vibration Transmitter |
| Bently Nevada | 990-05-XX-03-CN 104M6732-01 | Vibration Transmitter |
| Bently Nevada | 990-05-XX-03-CN 104M1359-01 | Vibration Transmitter |
| Bently Nevada | 990-05-XX-03-05 147202-01 | Vibration Transmitter |
| Bently Nevada | 990-05-XX-01-00 MOD:165335-01 | Vibration Transmitter |
| Bently Nevada | 990-05-XX-01-00 MOD:147202-01 | Vibration Transmitter |
| Bently Nevada | 990-05-70-02-05 | Vibration Transmitter |
| Bently Nevada | 990-05-70-02-01 | Vibration Transmitter |
| Bently Nevada | 990-05-70-02-00 | Vibration Transmitter |
Please contact us and look forward to our cooperation!
The 3500/22M 138607-01 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
3500/22M is a Transient Data Interface Module manufactured and designed by Bently Nevada as part of the 3500 Series used for monitoring seismic activity. The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
The 3500/33 16-Channel Relay Module is a full-height module that provides 16 relay outputs. You can place any number of 16-channel relay modules in any of the slots to the right of the Transient Data Interface (TDI) Module. Each output of the 3500/33 16-Channel Relay Module can be independently programmed to perform voting logic.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The 3500/60 133811-01 modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/72M Recip Rod Position Monitor meets API 618 requirements for reciprocating compressors. It measures: l Rod position l Rod drop l Hyper-compressor The four-channel 3500/72M Recip Rod Position Monitor accepts input from proximity transducers, conditions the signal to provide dynamic and static position measurements, and compares the conditioned signals with userprogrammable alarms. Each channel, depending on how you configure it, typically conditions its input signal to generate various parameters called measured values.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
