| Product module | 330104-03-06-10-02-00 |
| Brands | BENTLY NEVADA |
| Payment | Paypa/TT |
| Condition | 100% New |
| Weight | 0.12KG |
| Production year | 2024 |
| country of origin | USA |
330104-03-06-10-02-00 Proximity Probes Bently Nevada
overview
The Bently Nevada 330104-03-06-10-02-00 Proximity Probe is a precision instrument designed for accurate and reliable monitoring
of rotational and reciprocating machinery. As a key component of the renowned 3300 series, this proximity probe system is extensively
used in industrial environments to measure and monitor the displacement and vibration of critical machinery components.
Its advanced measurement capabilities ensure optimal machinery performance and enable the early detection of
potential issues, preventing unexpected downtime and reducing maintenance costs.
|
Contact us Email : sales@amikon.cn |
Specifications
| 330104-03-06-10-02-00 Proximity Probes |
|
| Operating Temperature | -51°C to +100°C (-60°F to +212°F) |
| Operating and Storage Temperature | -35°C to +200°C (-31°F to +392°F) |
| Vibration Resistance |
20 grms
|
| Frequency Response | 0 to 2.7 kHz: +0, -3 dB typical |
| Deviation from best fit straight line | Less than ±0.31 mm (±12 mils) |
| Average Scale Factor (ASF) | 0.787 V/mm (20 mV/mil) nominal |
| Dimensions | 1.8x1.5x113cm |
Graphs and Figures
|
7. 75Ω cable, 3.68 mm (0.145 in) maximum outside diameter, 3.94 mm (0.155 in) maximum outside diameter for FluidLoc cable, 7.67 mm (0.302 in) outside diameter of armor, 9.5 mm (0.38 in) maximum diameter of armor ferrule 8. Miniature male coaxial connector, 7.24 mm (0.285 in) maximum outside diameter “D” 9. Unthreaded length “A” 10.Case length “B” |
|
Product detailed description
Recommended model
| Bently Nevada | 330130-075-00-05 | 3300 XL Extension Cable |
| Bently Nevada | 330130-075-00-00 | 3300 XL Extension Cable |
| Bently Nevada | 330130-070-00-05 | 3300 XL Standard Extension Cable |
| Bently Nevada | 330130-070-00-00 | 3300 XL Standard Extension Cable |
| Bently Nevada | 330130-045-03-05 | 3300 XL 8mm Proximity Probes |
| Bently Nevada | 330130-045-03-00 | 3300 NSv Standard Extension Cable |
| Bently Nevada | 330130-045-02-05 | 3300 XL Standard Extension Cable |
| Bently Nevada | 330130-045-02-00 | 3300 XL Extension Cable |
| Bently Nevada | 330104-00-02-10-02-00 | 3300 XL 8mm Proximity Probe |
| Bently Nevada | 330130-045-00-05 | 3300 XL Extension Cable |
If you want to know more, please feel free to contact us via email: sales@amikon.cn
The 3500/22M 138607-01 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
3500/22M is a Transient Data Interface Module manufactured and designed by Bently Nevada as part of the 3500 Series used for monitoring seismic activity. The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
The 3500/33 16-Channel Relay Module is a full-height module that provides 16 relay outputs. You can place any number of 16-channel relay modules in any of the slots to the right of the Transient Data Interface (TDI) Module. Each output of the 3500/33 16-Channel Relay Module can be independently programmed to perform voting logic.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The 3500/60 133811-01 modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The 3500/72M Recip Rod Position Monitor meets API 618 requirements for reciprocating compressors. It measures: l Rod position l Rod drop l Hyper-compressor The four-channel 3500/72M Recip Rod Position Monitor accepts input from proximity transducers, conditions the signal to provide dynamic and static position measurements, and compares the conditioned signals with userprogrammable alarms. Each channel, depending on how you configure it, typically conditions its input signal to generate various parameters called measured values.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels. The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc. It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.
