GE DS200SDCCG1AGD DS215SDCCG1AZZ01B Drive Control Board
Features
| IC200CPU005 CPU Module Processor |
|
Part Number: DS200SDCCG4A DS215GASQG4AZZ01A |
|
Applicable to TC2000 turbines (same as G1A except with enlarged EE parameter storage area and different firmware) |
|
Five memory chips total, four EPROMs (U11, U12, U22, and U23) with factory-programmed configuration data and one EEPROM (U9) with field-adjustable parameters, make up the onboard software for the DS200SDCC card. On the SDCC, sockets house these memory chips. |
|
These features include the direct memory access (DMA) controller, timers/counters, an interrupt controller, wait-state generators, and address decoding for chip select. User interfaces, external regulating loops (such as speed and location), and system-level operations make up DCP software. |
|
Processor for Drive Control (DCP). An 80C186 microcontroller (U1) uses both digital and analog I/O and has many built-in peripheral features. |
|
Dimensions:28x21.2x3cm |
Funcrional Description
DS200SDCCG4A DS215GASQG4AZZ01A is a Drive Control Card manufactured and designed by General Electric
as part of the Mark V Series used in gas turbine Control Systems. The SDCC houses the main software and
circuitry for a drive or exciter. Three 16-bit microprocessors and related circuits make up the SDCC, which are
connected through dual-ported RAM. Dual-ported RAM [DPR] is RAM set up as memory arrays that two
microprocessors may access both independently and concurrently. Additionally, the SDCC has interface
circuitry that joins with other boards to create different kinds of ac and dc motor drives. The interface
circuitry manages and processes consumer I/O, drive, and motor signals.
Email :sales@amikon.cn
Skype :miyazheng520
Phone/WhatsApp : 86-18020776792
Frequently Asked Questions About DS200SDCCG4A DS215GASQG4AZZ01A
| Which applications is DS200SDCCG4A used in? |
|
DS200SDCCG4A is used in TC2000 turbine applications. DS200SDCCG4A and other G4A version SDCC's are the same as G1A versions except DS200SDCCG4A has enlarged EE parameter storage area and different firmware. |
| What are the three microprocessors on DS200SDCCG4A? |
|
DS200SDCCG4A has a Drive Control Processor (DCP), DS200SDCCG4A has a Motor Control Processor, and DS200SDCCG4A has a Co-motor Processor (CMP). |
| What kind of wires does DS200SDCCG4A have? |
|
DS200SDCCG4A has berg-type jumpers and DS200SDCCG4A has wire jumpers. Berg-type jumpers on DS200SDCCG4A are identified by a JP nomenclature. Wire jumpers on DS200SDCCG4A are identified by a WJ nomenclature. |
