GENERAL ELECTRIC DS200TBCAG1AAB Analog I/O Terminal Board

GE  DS200TBCAG1AAB  Analog I/O Terminal Board

Features

Details

Two blocks of 90 signal wire terminals and two 50-pin connections make up the GE Analog I/O Terminal Board

DS200TBCAG1AAB. If you can shift the signal wires from the old board's terminal blocks to the replacement

board's terminal blocks, replacing the GE Analog I/O Terminal Board DS200TBCAG1AAB is a simple task.

Due to the enormous energy held in the drive when linked to an electrical current, this procedure can only

be performed by a qualified servicer. Disconnect the drive from the power source that was installed to meet local

and national electrical requirements. The drive is powered by a power supply that converts AC power to DC power for

operation. It's also a good idea to look for the driver's emergency power shut-off devices. It is critical

to have at least two people working on the replacement in the event of an emergency.

• If an emergency arises, assistance is available to call for help or turn off the electricity using the emergency shutoff device.

Remove the damaged board with the signal wires still attached if feasible, and place it on a clean,

solid surface with an EDS protecting surface underneath it.

• A flat static protective bag, for example. Place the replacement board next to the old board while wearing a wrist strap.

And then relocate the signal wires from the old board to the new board one by one.

• Each module has one or more I/O packs that digitize sensor signals, conduct algorithms, and interact

with a separate controller that houses the main processor.

• A local processor board that runs a real-time operating system and a data acquisition

board that is specialized to the I/O application are included in I/O packs.
